MaxiCharger 80A Smart Home Level 2 EV Charger | 19.2kW
Couldn't load pickup availability
ℹ️ DESCRIPTION
Equip a suitable home charging location for high-power Level 2 AC charging with the Autel MaxiCharger 80A Residential EV Charger. The unit offers a compact charger and a fixed 25-foot SAE J1772 cable for supported North American EVs and plug-in hybrids.
The hardwired 208/240V model supports up to 80A / 19.2kW at 240V when connected to a 100A circuit for full output. Autel lists adjustable current settings from 16A through 80A, so lower power can be configured as appropriate. The vehicle's onboard AC charger must also support the target current; advertised mileage added per hour varies widely by vehicle.
Use the Autel Charge app for charging schedules, activity reports and charging-current settings. The model supports Wi-Fi, Bluetooth and Ethernet, as well as compatible Dynamic Load Balancing and Adaptive Load Management with additional equipment for the latter.
The supplier describes an IP65 / NEMA 4X enclosure, a modular charging-unit/wiring-box arrangement and a five-year product warranty on this residential 80A listing. This is the MaxiCharger 80A Home item, distinct from the AC Pro 80A listed separately. The supplied vehicle connector is J1772; compatible NACS vehicles require an appropriate separately obtained AC adapter.
FITMENT & COMPATIBILITY
✅ J1772-equipped EVs with Level 2 onboard charger and appropriate input current
✅ Compatible NACS vehicles through a separately obtained appropriately rated J1772-to-NACS AC adapter
✅ Hardwired 208/240V site; a 100A circuit is specified for 80A continuous charging
⚠️ Vehicle onboard AC limits or local circuit capacity can reduce actual charging power
WHAT'S INCLUDED❓
- 1 × Autel MaxiCharger 80A Residential charging station main unit and wiring-box assembly
- 1 × permanently attached 25-foot SAE J1772 charging cable
- Original manufacturer-supplied mounting accessories, quick reference guide and amperage labels
- ❌ Additional ALM equipment and J1772-to-NACS adapter not included
🟰 FEATURES
- Autel MaxiCharger Residential 80A charger
- 19.2kW maximum at 240V
- Up to 80A adjustable Level 2 output
- 16A to 80A charging-current settings
- 100A circuit required for full output
- Hardwired 208/240V AC connection
- Fixed 25-foot J1772 charging cable
- Autel Charge mobile app control
- Wi-Fi connectivity
- Bluetooth connectivity
- Ethernet connectivity
- Charging schedules and activity monitoring
- Compatible Dynamic Load Balancing
- ALM support with optional extra hardware
- Modular main-unit and wiring-box design
- IP65 / NEMA 4X supplier enclosure rating
- Five-year manufacturer storefront warranty
- Vehicle charging speed depends on onboard limits
